CSLB Low Voltage Systems (C-7): Study Guide and Online Practice Exam

$125.00 $225.00 Save $100.00 Free Shipping

Promo pricing through September 30, 2026.

41 diagrams in Low Voltage Systems (C-7) online practice

What’s included


What this covers

Per the state's classification, a C-7 contractor installs, maintains, tests, and repairs systems that use 91 volts or less, including telephone, data, video, intercom, alarm, and control wiring systems. This printed book covers the subjects the state tests. See the official CSLB C-7 classification.


Sample questions: Try our free practice test

  1. FTTC stands for:
    A. Fiber to the current · B. Fiber to the circuit · ✓ C. Fiber to the curb · D. Fiber to the CATV
  2. Why do you need Category 5e instead of Category 5?
    A. For greater strength for long pulls · B. To futureproof your network · C. For isolation in industrial networks · ✓ D. To run Gigabit Ethernet
  3. Copper networks can be converted to fiber networks by using:
    A. Patch panels · ✓ B. Media converters · C. Rewiring · D. Fiber hubs
  4. A convenient unit of measurement to compare the resistance and size of one conductor with another is the:
    ✓ A. ohm · B. mil-foot · C. wattage · D. voltage drop
  5. A GFCI breaker or receptacle will open a circuit where there is a current leakage to ground fault of:
    A. .06 · ✓ B. .006 · C. .6 · D. .2
  6. A megohmmeter is used to test insulation resistance because it provides a:
    ✓ A. higher potential than an ohmmeter · B. multiple path for resistance · C. convenient means of recording resistance · D. wide range of resistance taps

Practice with diagrams

41 diagrams in Low Voltage Systems (C-7) online practice

Read a sample diagram, choose an answer, then reveal the explanation. The online course includes diagram questions with feedback.

Link from transmitter to receiver with mated connections C1 through C4 and splices S1 and S2; the project-data panel gives component losses and optical specifications.
Fiber link loss and optical power · Open full-size diagram

Try a sample question

What is the predicted total passive loss of the illustrated link?

  1. 1.20 dB
  2. 0.40 dB
  3. 1.40 dB
  4. 2.40 dB
Show answer and explanation

C. 1.40 dB

Correct. Fiber contributes 0.40 × 0.50 = 0.20 dB, four connections contribute 1.00 dB, and two splices contribute 0.20 dB. Total = 1.40 dB.
